MOPA Laser Marker
Mainly used for alumina black, color marking on stainless steel, button light transmission, suitable for all metal materials.Widely used in medical equipment, mobile powersupply, mobilephone s…
PERFORMANCE CHARACTERISTICS
1. Flexible control, independently adjustable pulse width and frequency
2. Controllable pulse shape, wider adjustable parameter range and strong system upgrade
3. short pulse duration can quickly color stainless steel, alumina black
4. Features of no pollution, no noise, no consumables and low power consumption
APPLICATION AREA
Mainly used for alumina black, color marking on stainless steel, button light transmission， suitable for all metal materials.Widely used in medical equipment, mobile powersupply， mobilephone shell, tabletcomputer, rings，bracelets, watches, cups, glasses, clocks and watches, keys, instruments and meters, sanitaryware, household appliances, electronic components and soon.
Technical specifications
| Model | ZT-MPF20,ZT-MPF30,ZT-MPF50,ZT-MPF100 |
| laser power | 20W/30W/50W/100W |
| Wave length | 1064nm |
| Min.charaacter size | ≤0.4mm |
| Min.linear width | ≤0.1mm |
| Marking speed | ≤7000mm/s |
| Cooling way | air cooling |
| Machine weight | 80KG |
| Power consumption | 800W |
| Marking scope | 175m*175mm(optional) |
| Machine dimension | 750mm*940mm*1450mm |
| Power requirements | 220V±10/50HZ/60HZ |
